Product Name: LSOH Fire alarm Cable,

Style: Unshielded

Temperature: -20°C to 75°C

Type: Fire alarm Cable

Voltage: low

Wire Material: Solid Bare Copper

Wire Size: 22 AWG

Insulation and jacket: LSOH

Package: 100m or 200m plastic reel, 2 to 4 reels / carton.

Applications: Fire alarming system, smoke detector etc.

Detailed Constructions:

Number of Cores	Constructions	Material	OD (mm)
2C	Conductor	BARE COPPER (BC)	0.80mm
	Dielectric	LSOH	1.6mm
	Shield 1	PET
	Shield 2	SPECIAL FR MATERIAL
	Drain Wire	TINNED COPPER (TC)	0.80mm
	Shield 3	AL FOIL
	Jacket	LSOH	5.8mm

Special FR Material: Special High-Grade Fire-Resistant Material.
Cable constructions and specifications could be customized as per customer's requirements.

Application:
Suitable for use in fire alarm equipment, ventilation and smoke exhaust equipment, guide line lights etc.

Fire alarm Cable s a multi conductor electronic cable that comes in a shielded and unshielded version. The variations are PVC, Plenum, shielded and unshielded which automatically puts this cable in at least 4 types of different applications. Standard ways of asking for it would be fire alarm cable, shielded fire alarm cable, FPLR cable and FPLP cable which statnd for Riser and Plenum.

How to choice the right fire alarm cable you need?

Fire alarm cables are placed into three broad categories: plenum, non-plenum, and riser. Each of these corresponds to another standardized category. Plenum cable, to be used in ducts or other enclosed air spaces, is called FPLP; non-plenum cable, to be used in applications such as surface wiring, is FPL; and riser cable, which can be used in applications that go vertically from floor to floor, is FPLR. All of these names reflect where the fire alarm cable can be installed safely. Once you know where you will install the cable, you know in which category to start looking.

Special Features:

Made in China

Always competitive factory pricing
Strict Quality Control under ISO9001
Short Lead-time and Prompt Shipment always
European apporvals: CPR/CE/RoHS

North American approvals: ETL (UL application for control cable is undergoing)
OEM service available.
