Description:
Speaker Cable, CL3 & CM-Rated, 2-16 AWG stranded high conductivity bare copper conductors with polyolefin insulation, PVC / PE jacket with sequential footage marking every two feet.
Application:
This speaker cable is used to make the electrical connection between loudspeakers and audio amplifiers, and also used for the internal wiring of the speakers themselves.
Construction Parameters: | |
Center Conductor: | Bare Copper or Solid CCA (Copper Clad Aluminum) |
Construction: | 12/14/16/18 AWG |
Outer Sheathing: | PVC (Polyvinyl Chloride), Flameproof / PE (outer door). |
Jacket Overall Diameter: | 2.1*4.2±0.1mm (according to the conductor) |
Outer Jacket Colour: | Customization. with different color stripe is available. |
Packing: | 100/200/500M within an Plastic Reel. |
Making: | As required by customer |
Supplied on 100/200/500M Roll, housed within an Plastic Reel. | |
Maximum wire lengths for two conductor copper wire
Wire size | 2Ω load | 4Ω load | 6Ω load | 8Ω load |
22 AWG (0.326 mm2) | 3 ft (0.9 m) | 6ft (1.8m) | 9ft (2.7m) | 12ft (3.6m) |
20 AWG (0.518 mm2) | 5 ft (1.5m) | 10ft (3m) | 15ft (4.5m) | 20ft (6m) |
18 AWG (0.823 mm2) | 8 ft (2.4m) | 16ft (4.9m) | 24ft(7.3M) | 32ft (9.7m) |
16 AWG (1.31 mm2) | 12ft (3.6m) | 24ft (7.3m) | 36ft (11m) | 45ft (15m) |
14 AWG (2.08 mm2) | 20ft (6.1m) | 40ft (12m) | 60ft (18m)* | 80ft (21m)* |
12 AWG (3.31 mm2) | 30ft (9.1m) | 60ft (18m)* | 90ft (27m)* | 120ft (36m)* |
10 AWG (5.26 mm2) | 50ft (15m) | 100ft (30m)* | 150ft (46m)* | 200ft (61m)* |
