DETAILS:
22/4 Alarm Cable, unshielded
22AWG 4 Cores Alarm Cable / Security Cable / Control Cable, without shield
Constructions:
Number of Cores | Constructions | Material | Stranded Conductor | ||
4 | Conductor | BC/CCA |
| 7/0.254mm(22AWG) | 14/0.18mm |
Insulation | PVC/PVC-FR | ID | 1.2mm | 1.5mm | |
Sheath | PVC/LSOH | OD | 4.2mm | 4.8mm | |
Cable constructions could be adjusted as per client's request.
Jacket: PVC-FR: Fire Resistant PVC.
Electrical Properties (@20℃):
Rated Voltage (Max.) | 300V |
Rated Temperature | -15℃ to +70℃ |
Conductor Resistance (DC) | ≤5.08Ω/100m |
Insulation Resistance (DC) | ≧0.010Ω/km |
Mechanical Properties (@20℃):
Conductor breaking elongation rate | ≧15% |
Insulation tension | ≧16MPa |
Sheath tension before aging | ≧10MPa |
Insulation breaking elongation | ≧200% |
Sheath breaking elongation before aging | ≧125% |
Sheath breaking elongation after aging | ≧100% |
Note: the technical data changes with the different specifications.
Applications:
Widely used in Home Burglar Alarm, Public Security System, Intercoms, Telephone Stations, Speakers, Instrumentation, Control and other Low Voltage Circuits.
Standard Package:
Inner: 100-200m coil, 100-200m plastic reel, 305m-500m wooden reel etc.
Outer: Pull-box, master carton, with or without pallet
Length: 100m, 200m, 305m, 500m, 500ft, 1000ft....
Can be customized also.
Shipment Method:
*by SEA
Other delivery methods are available upon request from clients.
