Cable Specification:
Conductive material: Copper /CCA/CCS
Conductor insulation: HDPE
Shield: An aluminum-mylar (aluminum-polyethyleneterephthalate) tape is helically applied over the cable core, tape thickness - 0.025 mm, width - 18 mm; Shield thickness -0.04 mm
Drain wire: Tinned copper
The cable jacket: PVC/PE/LSZH
Jacket Color: Optional
Technical characteristics:
Dielectiric strength:2.5kv dc-2seconds
Conductor resistance:Max 9.38ohm/100m at 20°C
Max ring resistance:16.8ohm/100m at 20°C
Max mutual capacitance:530pf/100m
Max capacity unbalance:110pf/100m
Impedance:100±15%ohm at 1-250MHZ
resistance:16.8 ohm/100m at 20°C
Operating tempetature: -20°C~+70°C
Buyer's specification's are welcomed
Frequency | Return Loss | Attenuation(20°C) | DELAY | NEXT | NEXT Pwer Sum | ELFEXT | PSELFEXT |
(MHz) | ≥dB | ≤dB | ≤ns | ≥dB | ≥dB | ≥dB | ≥dB |
1 | 20.0 | 1.9 | 570.00 | 74 | 72.3 | 68 | 65.0 |
4 | 23.0 | 3.7 | 552.00 | 65 | 63.3 | 56 | 53.0 |
10 | 25.0 | 5.9 | 545.38 | 59 | 57.3 | 48 | 45.0 |
16 | 25.0 | 7.5 | 543.00 | 56 | 54.4 | 44 | 40.9 |
20 | 25.0 | 8.4 | 542.05 | 55 | 52.8 | 42 | 39.0 |
31.25 | 23.6 | 3.6 | 540.44 | 52 | 49.9 | 38 | 35.1 |
62.5 | 21.5 | 15.4 | 538.55 | 47 | 45.4 | 32 | 29.1 |
100 | 20.1 | 19.8 | 537.60 | 44 | 42.3 | 28 | 25.0 |
200 | 18 | 29.0 | 536.55 | 40 | 37.8 | 22 | 19.0 |
250 | 17.3 | 32.8 | 536.28 | 38 | 36.3 | 20 | 17.0 |
